RouterBOARD 912UAG with 600Mhz Atheros CPU, 64MB RAM, 1xGigabit LAN, USB, miniPCIe, built-in 5Ghz 802.11a/n 2×2 two, chain wireless, 2xMMCX connectors, RouterOS L4
RB911G-5HPacD
RouterBOARD 911G-5HPacD is our low-cost small form factor CPE board with 802.11ac support. It’s perfect for building low-cost 802.11ac CPE devices, as the list price is only $79. Yet, the device is very powerful- it’s equipped with 720MHz CPU, 128MB RAM, Gigabit Ethernet port, power jack and 1300mW 802.11ac 5GHz Dual Chain wireless onboard. Comes with RouterOS L3 license.
Product specifications
Details
Product code RB911G-5HPacD
CPU nominal frequency 720 MHz
CPU core count 1
Size of RAM 128 MB
10/100 Ethernet ports None
10/100/1000 Ethernet ports 1
MiniPCI slots 0
MiniPCI-e slots 0
Wireless chip model QCA9882-BR4A-R
Wireless standards 802.11ac
Number of USB ports 0
Power Jack 1
Supported input voltage 8 V – 30 V
PoE in Yes
PoE out No
Voltage Monitor Yes
CPU temperature monitor No
PCB temperature monitor Yes
Dimensions 105x105mm
Operating System RouterOS
License level 3
Antenna gain DBI No
Current Monitor No
CPU QCA9557-AT4A-R
Max Power consumption 12 W
SFP ports None
SFP+ ports None
Number of chains 2
Serial port None
Suggested price $79.00
