RouterBOARD 912UAG with 600Mhz Atheros CPU, 64MB RAM, 1xGigabit LAN, USB, miniPCIe, built-in 2.4Ghz 802.11b/g/n 2×2, two chain wireless, 2xMMCX connectors, RouterOS L4
RB912UAG-2HPnD
The RB912UAG-2HPnD is a very versatile device. It is a small wireless router with an integrated 2.4GHz high power wireless card and an additional miniPCIe slot for 802.11 wireless, or 3G card. The Gigabit port helps to utilize the full potential of 802.11n wireless speeds.
The integrated wireless card is capable of up to 1000mW output power. It has built in 16kV ESD protection on both the Ethernet and the MMCX ports.
Product specifications
Details
Product code RB912UAG-2HPnD
CPU nominal frequency 600 MHz
CPU core count 1
Size of RAM 64 MB
Architecture MIPS-BE
10/100 Ethernet ports 0
10/100/1000 Ethernet ports 1
MiniPCI slots 0
MiniPCI-e slots 1
Wireless chip model AR9342-BL1A
Wireless standards 802.11b/g/n
Number of USB ports 1
Power Jack 1
802.3af support No
PoE in Yes
Voltage Monitor Yes
CPU temperature monitor No
PCB temperature monitor Yes
Dimensions 105x105mm
Operating System RouterOS
Operating temperature range -30C to +60C
License level 4
Antenna gain DBI No
Current Monitor No
CPU AR9342-BL1A
SFP ports 0
SFP+ ports 0
USB slot type USB type A
Number of chains 2
Serial port None
Suggested price $79.00
